1050 aluminum sheet/coil belongs to commercially pure wrought family with a purity of 99.5% Aluminum.
Product Introduction
1050 aluminum sheet/coil belongs to commercially pure wrought family with a purity of 99.5% Aluminum. Except Al, 0.4% of Fe is added to 1050 aluminum sheet/coil, thus, it has high electrical conductivity. 1000 series aluminum group offers the best correction resistance compared to any alloy group, so does the 1050 aluminum sheet/coil. We can supply high quality 1050 aluminum sheet/coil with 16 years experience. Besides, different tempers are available, such as O (annealed), H12, H14, H18, etc.
| Elements | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others | Al |
| Content | 0.25 | 0.40 | 0.05 | 0.05 | 0.05 | - | 0.07 | 0.05 | 0.15 | Remain |
| Alloy Temper | Specified | Tensile strength | Yield strength | Elongation | ||||||
| Thickness(mm) | (MPa) | (MPa) | (%) | |||||||
| 1050-O/1050-H111 | 0.2-0.5 | 65-95 | Min20 | Min20 | ||||||
| 0.5-1.5 | Min22 | |||||||||
| 1.5-3.0 | Min26 | |||||||||
| 3.0-6.0 | Min29 | |||||||||
| 6.0-12.5 | Min35 | |||||||||
| 12.5-80.0 | ||||||||||
| 1050-H112 | 6.0-12.5 | Min75 | Min30 | Min20 | ||||||
| 12.5-80.0 | Min70 | Min25 | ||||||||
| 1050-H12 | 0.2-0.5 | 85-125 | Min65 | Min2 | ||||||
| 0.5-1.5 | Min4 | |||||||||
| 1.5-3.0 | Min5 | |||||||||
| 3.0-6.0 | Min7 | |||||||||
| 6.0-12.5 | Min9 | |||||||||
| 12.5-40.0 | ||||||||||
| 1050-H14 | 0.2-1.5 | 105-145 | Min85 | Min2 | ||||||
| 1.5-3.0 | Min4 | |||||||||
| 3.0-6.0 | Min5 | |||||||||
| 6.0-12.5 | Min6 | |||||||||
| 12.5-25 | ||||||||||
| 1050-H16 | 0.2-0.5 | 120-160 | Min100 | Min1 | ||||||
| 0.5-1.5 | Min2 | |||||||||
| 1.5-4.0 | Min3 | |||||||||
| 1050-H18 | 0.2-0.5 | Min135 | Min120 | Min1 | ||||||
| 0.5-1.5 | Min140 | Min2 | ||||||||
| 1.5-3.0 | Min2 | |||||||||
| 1050-H19 | 0.2-0.5 | Min155 | Min140 | Min1 | ||||||
| 0.5-1.5 | Min150 | Min130 | ||||||||
| 1.5-3.0 | ||||||||||
| 1050-H22 | 0.2-0.5 | 85-125 | Min55 | Min4 | ||||||
| 0.5-1.5 | Min5 | |||||||||
| 1.5-3.0 | Min6 | |||||||||
| 3.0-6.0 | Min11 | |||||||||
| 6.0-12.5 | Min12 | |||||||||
| 1050-H24 | 0.2-0.5 | 105-145 | Min75 | Min3 | ||||||
| 0.5-1.5 | Min4 | |||||||||
| 1.5-3.0 | Min5 | |||||||||
| 3.0-6.0 | Min8 | |||||||||
| 6.0-12.5 | ||||||||||
| 1050-H26 | 0.2-0.5 | 120-160 | Min90 | Min2 | ||||||
| 0.5-1.5 | Min3 | |||||||||
| 1.5-4.0 | Min4 | |||||||||
| 1050-H28 | 0.2-0.5 | Min140 | Min110 | Min2 | ||||||
| 0.5-1.5 | ||||||||||
| 1.5-3.0 | Min3 | |||||||||
Features and Applications of 1050 Aluminum Sheet/Coil
For its content above in the chart, 1050 aluminum sheet/coil has high ductility and high reflective finish. Besides, 1050 aluminum sheet/coil is non-heat treatment series is produced in extruded sections. It has excellent cold workability, braze-ability and solder-ability, and it is strengthened by cold working. However, 1050 aluminum sheet/coil has low mechanical strength compared to more significantly alloyed metals. All of these characteristics make 1050 aluminum sheet/coil well suited to chemical and electrolytic brightening but not in casting. Last but not least, moderate strength and good anodizing quality enables our products has a vast application.
Packaging and Delivery
Aluminum products of Yinhe Aluminum meet the export standard. Plastic film and brown paper can be covered at customers’ need. What’s more, wooden case or plywood box is adopted to protect products from damage during the delivery. There are two kinds of packaging, which is eye to wall or eye to sky. Customers can choose either of them for their convenience. Generally speaking, there are 2 tons in one package, and loading 18-22 tons in 1×20′ container, and 20-24 tons in 1×40′ container.
